ES4 WC

Featured Image: Green Building Store water saving siphon flush ES4 WC

4/2.6 litre dual flush water saving WC, with leak-free siphon flush. Wall-hung and back-to-wall versions.

  • 4 litre/ 2.6 litre dual flush or 4 litre only
  • WRAS-approved
  • Leak-free siphon
  • 2.6 litre lower flush option
  • Robust seat (10 year guarantee)
  • Chrome handle with wide range of spindle lengths
  • Palm push button mechanism option (for blockwork installations)

WRAS certificate and testing data – download pdf

  • Suite: Concealed styrene cistern with either back-to-wall floor standing pan or wall-hung pan in ceramic.
  • Flush type: Single siphon.
  • Servicing: Thomas Dudley two-part siphon.
  • Flush volume: 4 litres (2.6 litre lower flush option)
    Inlet: Ecofil delayed action valve HP/LP*
    Durability: 1 million cycles +
    Seat: Pressalit white duroplastic or maple, with lid.
    Outlet: Standard 110 mm horizontal.
    Accessibility: Available as part of Doc M pack to BS 8300.
  • Handle: Chrome handle with anti-vandal features and stop to protect siphon from over-use. Available with a variety of spindle lengths up to 450mm.
  • Palm push button mechanism is also an option for blockwork wall installations.
  • Disabled use flush handle also available as part of Doc M pack

* Please note Ecofil inlet valves are not suitable for rainwater harvesting systems. If rainwater is to be used to flush the ES4, an ordinary float valve should be used.
